BR(WR) Grange class 4-6-0 no. 6809 Burghclere Grange

6809 Burghclere Grange
6809 Burghclere Grange
BR(WR) Grange class 4-6-0 no. 6809 Burghclere Grange.

This model was built by J.K.Stansfield of Colne in 1993, from the Malcolm Mitchell kit. The motor/gear unit is by ABC and the wheels are good quality cast iron. The pick-ups are of the plunger type and it all has been built to a very professional and well detailed standard. Since then it has been displayed unpainted in a glass case. After purchase, it has been thoroughly cleaned and serviced to excellent running condition by myself and expertly painted and weathered by John Cockcroft. The model even has a tender makers plate with the correct number, 1898, all part of the excellent service from Severn Mill nameplates.

Only two of the Granges were given the British Railways mixed traffic lined black livery. 6809 in December 1949 when the loco was allocated at Penzance, having a 3500 gallon Churchward pattern tender at the time. The other, number 6819 having the Collett intermediate pattern tender when it was painted in lined black at Caerphilly in 1955. All other Granges were painted plain black, until green became the standard livery for the class in the late 1950’s.

BR (ex LSWR) IOW O2 class no. W22 Brading

W22 Brading

W22 Brading
BR (ex LSWR) IOW O2 class no. W22 Brading. Built by myself from the Alan Gibson kit with Gibson wheels and an ABC motor/gear unit. Warren Haywood takes the credit for the superb painting.

Models of these delightful little Isle of Wight locos rarely appear and even more rarely come up for sale. I was fortunate to be taken to the Isle of Wight on holiday when in my early teens and I still have a photo of Brading, taken on the small turntable at the end of the line at Ventnor. Thus the motivation for me to buy and build this kit. Check out Jim McGowan’s Connoiseur website http://www.jimmcgeown.com/Photo%20Gallery%20Customers%20Models/Southern%20Class%2002%20Photo%20Gallery.html for more photos of models of these locos. (All in green livery? None in black, I wonder why??)

I bought this kit in completely untouched condition from a good friend, now deceased, who had decided to sell his collection because of health problems. He had bought it probably 30 years previously and it had lain in the bottom of his wardrobe ever since. Now here it is built, painted and running like a dream and none the worse for spending all of those years in the dark.

Southern Railway King Arthur class 4-6-0 no. E785 Sir Mador de la Porte

E785 Sir Mador de la Porte

E785 Sir Mador de la Porte
Southern Railway King Arthur Class no. E785 Sir Mador de la Porte. This model was built by myself many years ago from the Modern Outline kit, with Slaters wheels and an ABC motor/gear unit. I originally painted it in an identical livery as E792 Sir Hervis de Revel and with that identity he gave me many years excellent service, but unfortunately the paint deteriorated, resulting in me stripping it for a repaint. New paint, new identity. Now expertly painted by Warren Haywood. The model as Sir Mador is now all ready to give many more years service.

LNER Gresley A1 class Pacific no. 1470N Great Northern

Great Northern

Great Northern
LNER Gresley A1 class Pacific no. 1470N Great Northern. Built (to 95% completion) from scratch by Walter (Wally) West circa 1980’s using driving wheel castings by Alan Harris and a massive Pittman gear and motor unit. For a reason unknown Great Northern (and his twin brother Robert the Devil, who appears on a separate posting on this site) were left unfinished until in early 2020, when I was commissioned by Wally’s family to complete the models. This entailed, in the main, the soldered assembly of cab parts and the fitting of all handrails on the boiler, cab and tender. It also entailed the preparation of the model for final painting by Warren Haywood. I am very proud to have completed the model to a standard worthy of the builder and honoured to have this fabulous model as part of my collection.

BR Britannia class 4-6-2 no. 70006 Robert Burns

Robert Burns

Robert Burns
BR Britannia class 4-6-2 no. 70006 Robert Burns. A Masterpiece model loco, obtained in a swap deal, second hand and with only very minor repairs needed, otherwise mint condition. Switchable DC/DCC and sound. Truly amazing detail and surprisingly robust. I have photographic evidence that I spotted the original loco heading south on a goods train, at the signals at Syston North Junction, waiting to go round the sharp curve towards Melton Mowbray in 1966. Admittedly she was without nameplates and didn’t look as clean as depicted in the model, but still great memories.

North Eastern Railway Tennant 2-4-0 no. 1477

NER Tennant 2-4-0 1477

North Eastern Railway Tennant 2-4-0 no. 1477. Expertly scratch built and painted (circa late 1950’s) by Bernard Miller with hand painted lettering and numerals in the fully lined NER passenger green livery. Built with very fine quality cast wheels and a John Hart RM (short) type motor no. 862. She collects power from the tender wheels and from plunger pick-ups on the loco. A belt and braces job and there is nothing wrong with that. This model was built for the famous layout of Stanley Norris and featured in the Model Railway News magazine of February 1960 and in the Railway Modeller magazine of January 1971 when on a visit to Wally Mayhew’s Stanley to Stratford St. Andrew layout.

On Bernard’s passing in 1980 she was obtained by Arthur Dewar and is shown on Arthur’s layout in Jack Ray’s book ‘Model Railways and their builders’ published by Atlantic Press. She also featured in the Gauge O Guild Gazette on Arthur’s layout (see page 338 of the link at the bottom of this page). On Arthur’s death she passed onto Wally West and as part of his collection she has now found her way into my collection.

When obtained, her paintwork had deteriorated with age, the black paint on the outside frames in particular had become unstable and had worn away completely in places. Fortunately, most of the green areas have survived well. I have now had Bernard’s paint restored by the museum conservator John Cockcroft, who has managed to preserve the hand painted numbers and lettering. I must say that he has made a superb job of it. A powerful loco, I have had her pulling eight coaches with ease. A good load for a 2-4-0.

https://www.gaugeoguild.com/secured/gazette_archive/Vol11-10//offline/download.pdf

LMS Stanier Jubilee class 4-6-0 no. 5703 Thunderer

LMS Stanier Jubilee class 4-6-0 no. 5703 Thunderer

LMS Stanier Jubilee class 4-6-0 no. 5703 Thunderer. Built from scratch by Michael Edge and carries his builders plates on the underside as provenance. Portescap motor and gear unit. Bought from the O gauge Guild executors service as 5579 Punjab, but Punjab was never a long firebox Jubilee in LMS days, so we had it changed and thanks to John Cockcroft for making such a good job of it.

Great Central Railway class 8 4-6-0 (Fish engine) no.1067

Great Central Railway class 8 4-6-0 (Fish engine) no.1067
GCR Robinson class 8 4-6-0 no. 1067. Built from scratch by Wally West circa mid-seventies, using a JH motor and a double reduction gear unit, with wheels turned from good castings. probably by Miller, Swan & Co. The split axles and insulated spacers between the frames allow power to be collected from the tender wheels, via sprung plungers mounted on the front face of the tender, connecting with contact faces on the back of the loco. All brake blocks are made from non conductive material to eliminate shorting across the brake rigging. All loco driving and tender axles have sprung hornblocks. Superbly painted by Bernard Miller with hand painted lettering and crests in lined GCR mixed traffic livery. An identical twin of this model, also numbered 1067, was built by Wally at the same time. That model has since had water scoop apparatus fitted to the tender by Geoff Holt and has also had it’s paint stripped and has been repainted by Alan Brackenborough. My model above has had it’s smokebox door replaced by, in my opinion, a more accurate representation, rail jacks added either side of the smokebox and a pair of whistles (replacing a single one) added to the cab roof. So no longer are they identical.

Great Northern Railway Ivatt class C1 4-4-2 no. 990 Henry Oakley

Great Northern Railway Ivatt class C1 4-4-2 no. 990 Henry Oakley
GNR Ivatt class C1 4-4-2 no. 990 Henry Oakley. Built in 1966 from scratch by Walter (Wally) West, using a Pittman DC81 motor and gear unit. With the knowledge of the friendship between Wally and Bernard Miller at the time of build, it is very likely that the wheel castings are from the Miller Swan & Co. range. The split axles and insulated spacers between the frames allow power to be collected from the tender wheels, via sprung plungers/tender buffers, connecting with contact faces on the back of the loco. All brake blocks are made from non conductive material to eliminate shorting across the brake rigging. All loco driving and tender axles have sprung hornblocks. Superbly painted by Bernard Miller with hand painted lettering and numerals in the fully lined GNR passenger green livery.
I have a dislike of collecting models of preserved locos, but as the model is in it’s short smokebox (saturated) condition and the preserved loco has a long smokebox it is not a model of the loco as preserved. In fact the preserved loco wasn’t superheated until 1923, so I think I’m correct in saying that it would not have carried the GNR livery, as it has since it has been preserved, whilst it had a long smokebox.
A letter has come to light dated March 10th 1966 where Bernard tells Wally “I am delighted to hear about the GN Atlantic and shall look forward to seeing it very much indeed. Wally M. (Mayhew) tells me that you are also building one for him”.
This model, according to Wally’s widow Mary, was his favorite and for it’s age has been rarely used. The paintwork has needed no repairs and it still runs like a dream. The Gauge O Guild Gazette of January 1968 lists a “GNR 4-4-2 (Mr. West)”, on display at the A.G.M. of 1967 and of January 1969 a “GNR 4-4-2 Klondyke by W. West”, is listed as being on display at the A.G.M. of 1968.

BR(ex GWR) 2301 class 0-6-0 Dean Goods no. 2538

Dean Goods 2538
BR (ex GWR) Dean Goods 0-6-0 no. 2538. This model has been skillfully built from scratch, the loco in nickel silver and the tender in brass. It would seem that the unknown builder sadly passed away before he could finish it, as I found and bought it out of the Gauge O Guild Executors and Trustees Service. The build was 95% complete, but needing very much TLC before painting by myself and weathering by Richard Pogson. She now runs very well and looks good too.
I have modeled her as the last member of the class to be withdrawn, in 1957 from Oswestry shed. She outlived her now preserved sister no. 2516 by a year, becoming something of a celebrity and being kept in reasonably clean condition for hauling special trains. The two locos had been retained principally for working the Abermule – Kerry branch line.
